Bio Safety Cabinet Class III (Glove Box)

We offer Class III Bio Safety Cabinets are provide total barrier protection for the operator, Product, environment and are suitable for extreme bio-hazard group 4 work. Class III biological safety cabinets are Air-tight and inflow air is HEPA filtered before entering the Class 3 Biological Safety Cabinet via a side mounted inlet filter chamber. Exhaust air is HEPA filtered before leaving the safety cabinet via a single or double HEPA filter, dependant on the customers specific technical requirements. According to the Filter life and Energy saving, we having 3 models are ..

1. Basic Model 2. Standard Model 3. Superior Model



Total enclosure of the working area

User separated from the work by a physical barrier

Filtered air continuously supplied to the safety cabinet

Exhaust air treated to prevent contamination

Creates total protection for user and materials

Manipulations within the Class 3 Biological Safety Cabinet are carried out via gloves mechanically attached to the cabinet providing a total seal against any particulate contamination released within the main working area. Only Class 3 cabinets which are totally enclosed units are suitable for work with Group 4 hazards.



MOC of Construction:

1. Fully SS 304 construction with PVC mat 4 finish.

2. GI Powder coating / Painting Constriction with SS 304 working area and work bench.



Technical Specifications:

Direction of flow : Vertical

Cleanliness : CLASS 100

Air Balancing : 0% recirculation and 100% Fresh air

Inflow Velocity : 0.53 M/s

Down flow Velocity : 0.33 M/s

HEPA Filter : 0.3micron with 99.997% efficiency

Particle retention : Above 0. 3 micron

Blower Assembly : 1 / 3 HP, 1440 RPM

Noise level : 65 decibel + / -5%

Vibration level : < 2. 5 micron



Fittings:

Microprocessor based Control systems and feather touch switches

RPM regulator / VFD controller

Magnehelic Gauge / Mano meter and Gas Nipple

Velocity sensors and Digital display systems

CFL Lighting and Germicidal (UV) Lamp with Hour meter



Clients:

Medical Testing Lab, Hazardous material handling area, Blood testing labs etc.,
